Characteristics

Rated Power........................................................................DC 5V 5mA(0.5mA Min) Fluttering............................................................................T1,t3 3ms Insulation Resistance............................................................More than 10mΩ at Dc m 50v 1 Α Withstand voltage................................................................1 minute at AC 50V 1mA Sliding Nosie(Bounce)..........................................................T2 2ms Phase Difference................................................................. T 0.08T Rotation Torque of Detent.....................................................30 ~ 130gf.cm Rotation Torque Rang...........................................................10 ~ 90gf.cm Total Rotational Angle..........................................................Continuous Number and Position of Detent..............................................12 Detents (Angle: 30° 3°) 24 Detents (Angle: 15° 3 ) ° ± ± Push-Pull Strength .............................................................. 8.0kgf Min for 10s Push & Nut Tight Strength ................................................. 10.0kgf Min
